Official DUCATI Press Release - 2003 Multistrada 1000 DS
|
|
ENGINE |
|
| Type | L-twin cylinder, 2 valve Desmodromic, air cooled |
| Displacement | 992 cc |
| Bore x Stroke | 94 x 71,5 mm |
| Compression Ratio | '10:1 |
| Power | 62 kW - 84 HP @ 8000 rpm |
| Torque | 84 Nm - 8.5 Kgm @ 5000 rpm |
| Fuel injection | Marelli electronic fuel injection, 45 mm throttle body |
| Exhaust | Exhaust system with single steel muffler, with pre-silencer and catalytic converter (non-catalytic on USA version) |
|
Transmission |
|
| Gearbox | 6 speed |
| Ratios | 1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28 |
| Primary drive | Straight cut gears, ratio 1.84 |
| Final drive | Chain; Front sprocket 15; Rear sprocket 42 |
| Clutch | Dry multiplate with hydraulic control |
|
CHASSIS |
|
| Frame | Tubular steel trellis frame |
| Wheelbase | 57.6 in |
| Rake | 24° |
| Front suspension | Showa 43 mm fully adjustable upside-down fork |
| Front wheel travel | 6.5 in |
| Front brake | 2 x 320 mm semi-floating discs, 4-piston, 2-pad caliper |
| Front wheel | New 6-spoke design in light alloy 3.50 x17 |
| Front tyre | 120/70 ZR 17 |
| Rear suspension | Progressive linkage with fully adjustable Showa monoshock; hydraulic remote pre-load control |
| Rear wheel travel | 5.6 in |
| Rear brake | 245 mm disc, 2-piston caliper |
| Rear wheel | 5-spoke light alloy 5.50 x 17 |
| Rear tyre | 180/55 ZR 17 |
| Fuel tank capacity | 20 l / 5.3 U.S. gal |
| Weight * | 441 lbs |
| Seat height | 33,5 in |
| Instruments | Speedometer, rev counter, clock, scheduled maintenance warning, warning light for low oil pressure, fuel level, oil temperature, fuel reserve,neutral, turn signals, average speed, average fuel consumption, fuel injection diagnostic system, immobilizer |
| Warranty | 2 years unlimited mileage |
| Tank and fairing Colours | Two-tone grey, red |
| Frame and wheel colours | black, red |
| Wheels colours | light grey |
| * = The weight includes battery, lubricants and, where applicable, cooling liquid. | |
